SILVAN 400L (6M BOOM) REDLINK LINKAGE SPRAYER

400L Redlink Linkage Sprayer: BP60/20 pump, reel, hose & gun, 6m Econopak boom

Specifications:

Market: Dairy & Livestock. Ag Lifestyle.
Tank Size (L): 400
Connection Type: Linkage (3PL)
Pump Size (L/min): 58
Height/ Width/ Length (mm): 1330 / 2060 / 1200
Product Weight (kg): 121

Features:

Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and cast anodised aluminium body. BP60/20: 58 L/min. capacity 2000kPa pressure.

Boom: Econopak boom: 6m with stainless steel spray lines, non-drip nozzle holders, fully galvanised frame and spring loaded safety break back/forward.

Nozzles: Air induction nozzles with strainer in bayonet fit non-drip nozzle holders at 50cm spacings.

Controls: 3 outlet manual control valve with pressure regulator. Mounted forward for easy access.

Tank: Polytuff impact resistant polyethylene construction, moulded litre calibrations and non-spill screw-down lid with single breather.

Frame: Fully galvanised steel, cat I & II linkage.

Agitation: Bypass agitation.

Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.

Filtration: Lid strainer, suction line strainer and nozzle strainers.

Hose Reel: Fitted with rear-mounted Eco hosereel, 30m of 10mm hose and Spotjet spraygun with adjustable spray nozzle.

PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.

Options:

- 14L Foam marker (single side)
- 16L foam marker (double side)



All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!

Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.
